colorPol® IR polarizer

發布時間: 2020-09-21 10:35

CODIXX

colorPol® IR polarizer在近距至中距紅外線光譜範圍中應用。高對比度、高透射率、寬光譜帶寬
colorPol® IR polarizer 主要參數

colorPol® IR polarizer 特點：

colorPol® IR polarizer 系列規格：

colorPol^® 型號	波長範圍 [nm]	穿透率 [%]	對比	厚度[µm] 未壓層	厚度[mm] 壓層	尺寸 [mm²]	PDF
NIR	1,000-2,700 2,700-3,000	>77 >70		250+/-65	2.0+/-0.2 at other wavelength ranges	<=100x60	colorPol® NIR
NIR	1,200-3,000 1,000-3,000		>10,000:1 >1,000:1	250+/-65	2.0+/-0.2 at other wavelength ranges	<=100x60	colorPol® NIR
MIR	2,000-4,500 1,500-5,000	>65-90 >35-90	>10,000:1 >1,000:1	200+/-50	-	<=100x50	colorPol® MIR
Contrast ratios ≥ 100,000:1, other thicknesses, shapes or dimensions on request. Reflection losses can be minimized by antireflection coating. AR-coatings are available for different wavelength ranges as V-coating or wide-band version.
